304 BA Mirror Finish Stainless Steel Square Tube with TIG Welded Construction for Corrosion Resistant Handrails

Name: 304 BA Mirror Finish Stainless Steel Square Tube with TIG Welded Construction for Corrosion Resistant Handrails
Brand: ShanXi TaiGang Stainless Steel Co.,Ltd
SKU: 304-BA-AT-01
Price: 4.50 USD
Availability: InStock

All Products

Stainless Steel Flat Sheet
(52)

Stainless Steel Square Tube
(44)

Stainless Steel Rectangular Tube
(38)

Stainless Steel Seamless Pipe
(26)

Stainless Steel Welded Pipe
(19)

Stainless Steel Coil
(29)

304 1/2H 3/4H H Stainless Steel Coil
(25)

301 1/2H 3/4H H Stainless Steel Coil
(17)

Stainless Steel Strip
(25)

Titanium Alloy Steel
(8)

Nickel Based Superalloys
(6)

Stainless Steel Rod Bar
(12)

Stainless Steel Angle
(14)

Stainless Steel Channel
(12)

Stainless Steel Flat Bar
(10)

Aluminum Alloy Bar
(13)

Round Aluminum Bar
(17)

Best Products

AISI Stainless Steel Square Tube

Q195 304 Stainless Square Tubing

Mirror Polished SS 304 Square Pipe

Certification

I'm Online Chat Now

304 BA Mirror Finish Stainless Steel Square Tube with TIG Welded Construction for Corrosion Resistant Handrails

Large Image : 304 BA Mirror Finish Stainless Steel Square Tube with TIG Welded Construction for Corrosion Resistant Handrails

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	TGPX
Certification:	ISO 9001:2015, ASTM A554, EN 10357, RoHS
Model Number:	304-BA-AT-01

Payment & Shipping Terms:

Minimum Order Quantity:	500 Kilograms
Price:	USD 3.50-5.80 / Kilogram
Packaging Details:	PE protective film wrapped, end caps, packed in fumigation-free plywood case
Delivery Time:	5 working days for stock, 15-25 days for production
Payment Terms:	T/T, L/C, PayPal, Western Union
Supply Ability:	50000 Kilograms per Month

Contact Now

304 BA Mirror Finish Stainless Steel Square Tube with TIG Welded Construction for Corrosion Resistant Handrails

Description

Steel Grade:	304 (1.4301 / S30400)	Standard:	ASTM A554, EN 10357, JIS G3446
Surface Finish:	BA (Bright Annealed) Mirror	Wall Thickness:	1.0mm - 4.0mm
Section Size:	15x15mm To 100x100mm	Length:	6000mm Standard (3000mm / Custom Available)
Temper:	Bright Annealed	Weld Type:	TIG Welded, Weld Bead Controlled
Application:	Handrails, Balustrades, Interior Decoration, Furniture, Shop Fittings, Exhibition Displays
Highlight:	BA Finish Square Tube , Architectural Stainless Tubing , Mirror Decorative Square Pipe

304 BA Mirror Finish Architectural Stainless Steel Square Tube

The 304 BA (Bright Annealed) mirror finish stainless steel square tube delivers a premium chrome-like reflective aesthetic for architectural and interior design applications where visual impact and surface brilliance are primary selection criteria.

Superior Finish Technology: Unlike electroplated finishes that can peel, chip, or discolor over time, the BA finish is achieved through a controlled atmosphere bright annealing process. This metallurgically integral surface finish provides consistent reflectivity and color tone that cannot delaminate or wear away, maintaining its decorative appearance throughout decades of service.

The 304 austenitic stainless steel grade (1.4301/S30400) provides excellent atmospheric corrosion resistance in indoor and sheltered outdoor environments, making it the industry standard for handrail systems, balustrade infill tubes, architectural column cladding, furniture frames, and retail display fixtures.

Key Features

Bright Annealed Mirror Finish: BA surface delivers bright, reflective appearance comparable to #8 mirror polished sheet metal, achieved without mechanical polishing through controlled atmosphere heat treatment
No Electroplating Required: Integral BA finish eliminates environmental compliance issues, hydrogen embrittlement risk, and peeling/flaking problems associated with plated finishes
Consistent Color and Reflectivity: Uniform silvery-white surface color throughout production lots ensures visual consistency in architectural projects
Excellent Indoor Corrosion Resistance: 304 stainless steel resists tarnishing from humidity, fingerprints, and mild cleaning chemicals
Weldable Without Finish Damage: TIG welding with argon back-purge protection produces clean, minimal-discoloration welds
Design Flexibility: Square profile with crisp corner radii provides clean modern lines compatible with standard architectural hardware

Technical Specifications

Parameter	Specification
Steel Grade	304 (1.4301 / S30400 / 06Cr19Ni10)
Chemical Composition (Cr)	18.0 - 20.0%
Chemical Composition (Ni)	8.0 - 10.5%
Surface Finish	BA (Bright Annealed) Mirror
Wall Thickness	1.0mm - 4.0mm
Section Size	15x15mm to 100x100mm
Corner Radius	1.0T - 2.5T (T = wall thickness)
Weld Type	TIG Welded, Bead Controlled
Length	6000mm standard (3000mm / custom available)
Tensile Strength (Rm)	520 MPa min
Yield Strength (Rp0.2)	205 MPa min
Applicable Standards	ASTM A554, EN 10357, JIS G3446

Applications

304 BA mirror finish stainless steel square tubes are the preferred material for premium architectural handrail and balustrade systems in commercial buildings, shopping centers, airports, hotels, and high-end residential developments.

In retail environments, BA square tubes are widely used for display fixture construction including clothing rails, shelving support frames, merchandise presentation stands, and point-of-sale counters. Furniture designers specify these tubes for table bases, chair frames, shelving units, and decorative room dividers.

Exhibition stand builders and interior fit-out contractors utilize BA square tubes for modular structures, graphic panel frames, lighting support systems, wall cladding supports, and column wrapping frameworks in corporate offices, hotels, and restaurant interiors.

Packaging & Quality Assurance

Each tube is wrapped with clear PE protective film with UV inhibitors and fitted with plastic end caps to prevent damage during handling and installation. Tubes are packed in ISPM 15 compliant fumigation-free plywood cases with foam interleaving separators.

Each shipment includes an EN 10204 3.1 inspection certificate with chemical analysis, mechanical properties, and dimensional conformance reports. Our ISO 9001:2015 certified quality system maintains full traceability from certified 304 stainless steel coil through every manufacturing operation.

Delivery: Standard stock sections ship within 5 working days; custom dimensions within 15-25 working days. We recommend retaining protective film throughout fabrication and removing only after final installation cleaning.
