Thin Wall 304 Stainless Steel Square Tube with 0.5mm-3mm Wall Thickness for Lightweight Structural Applications

Large Image : Thin Wall 304 Stainless Steel Square Tube with 0.5mm-3mm Wall Thickness for Lightweight Structural Applications

Product Details:

Place of Origin:	Jiangsu, China
Brand Name:	TGPX
Certification:	ISO 9001:2015, ASTM A554, EN 10357, RoHS
Model Number:	304-TW-ST-01

Payment & Shipping Terms:

Minimum Order Quantity:	500 Kilograms
Price:	USD 3.00-5.20 / Kilogram
Packaging Details:	PE film wrapped, end caps, bundled with steel straps, packed in fumigation-free plywood case
Delivery Time:	5 working days for stock, 15-25 days for production
Payment Terms:	T/T, L/C, PayPal, Western Union
Supply Ability:	60000 Kilograms per Month

Contact Now

Thin Wall 304 Stainless Steel Square Tube with 0.5mm-3mm Wall Thickness for Lightweight Structural Applications

Description

Steel Grade:	304 (1.4301 / S30400)	Standard:	ASTM A554, EN 10357, JIS G3446
Surface Finish:	Satin / 2B / Polished 320 Grit	Wall Thickness:	0.5mm - 3.0mm
Section Size:	12x12mm To 80x80mm	Length:	6000mm Standard (3000mm Available)
Temper:	Annealed	Weld Type:	TIG Welded, Smooth Bead
Application:	Furniture Frames, Display Racks, Retail Shelving, Exhibition Booths, Light Architectural Structures
Highlight:	Thin Wall Square Tube , Lightweight Stainless Tubing , Furniture Display Tube

Thin Wall 304 Stainless Steel Square Tube 0.5mm-3mm Precision for Furniture Display Rack Light Structure

The thin wall 304 stainless steel square tube is specifically engineered for weight-sensitive structural applications in the furniture, retail display, and light architectural industries. It offers an optimal balance of structural integrity and material economy, with wall thicknesses ranging from 0.5mm to 3.0mm. This construction achieves weight reductions of 40-70% compared to standard-wall structural tubing of equivalent section size, resulting in lower material costs, reduced shipping expenses, and easier manual handling.

Key Features

Weight Reduction 40-70%: Dramatically reduces tube weight compared to standard-wall structural tubing, lowering material cost per meter, shipping charges, and handling effort.
Cost-Effective Material Usage: Optimized thin wall design delivers required structural performance while minimizing stainless steel consumption.
Square Profile Torsional Rigidity: Square cross-section provides higher torsional stiffness than round tube of equivalent area, resisting twisting under asymmetrical loading.
Precision Roll Forming: Advanced multi-stage roll forming ensures consistent corner radii and wall thickness within close tolerances.
Uniform Satin Surface Finish: Satin/320 grit polished surface provides clean, professional appearance with consistent grain direction.
Easy Fabrication: Can be cut, drilled, welded, and formed using standard metalworking tools with TIG welding for clean, minimal-distortion joints.

Technical Specifications

Parameter	Specification
Steel Grade	304 (1.4301 / S30400 / 06Cr19Ni10)
Chemical Composition (Cr)	18.0 - 20.0%
Chemical Composition (Ni)	8.0 - 10.5%
Wall Thickness	0.5mm - 3.0mm
Wall Thickness Tolerance	10% of nominal wall thickness
Section Size	12x12mm to 80x80mm
Corner Radius	1.0T - 3.0T (T = wall thickness)
Surface Finish	Satin / 2B / Polished 320 Grit
Length	6000mm standard (3000mm available)
Tensile Strength (Rm)	520 MPa min
Yield Strength (Rp0.2)	205 MPa min
Weld Type	TIG Welded, Smooth Bead
Applicable Standards	ASTM A554, EN 10357, JIS G3446

Applications

Thin wall 304 stainless steel square tubes are essential in contemporary furniture design, combining lightweight construction, modern aesthetics, and corrosion resistance. Applications include:

Office Furniture: Desk frames, pedestal legs, monitor stand supports, and cable management channels in workstation systems.

Retail Display: Structural framework for clothing display rails, merchandise shelving, gondola systems, and point-of-purchase displays.

Exhibition & Trade Shows: Modular booth frameworks, graphic panel supports, lighting truss components, and information desk frames.

Hospitality Furniture: Table bases, bar stool frames, room dividers, and outdoor patio furniture under covered conditions.

Architectural Metalwork: Lightweight balustrade infill bars, decorative screening panels, sun shading louver frames, and suspended ceiling grids.

Packaging & Quality Assurance

Each tube is individually wrapped in PE film and bundled with cardboard interleaving separators. Bundles are secured with non-metallic strapping and packed in ISPM 15 compliant plywood cases. Every shipment includes EN 10204 3.1 material certification with chemical composition, mechanical properties, and dimensional reports.

Our ISO 9001:2015 certified quality system ensures consistent product quality through in-line dimensional monitoring, visual weld inspection, and surface finish verification. Standard stock sizes ship within 5 working days; custom requirements are fulfilled within 15-25 working days.

Value-added services include precision cut-to-length, end deburring, and pre-drilling for assembly hardware, delivering ready-to-assemble tube kits directly to manufacturing facilities.
